PAX HD
column formwork

Applications

The fastest way to build formwork for square and rectangular columns

In terms of the area of formwork required, an enormous amount of work is required to set up formwork in the traditional way for different types of square or rectangular column. Minimising this work and at the same time retaining flexibility in terms of height and cross-section was the brief for the development of a completely new type of column formwork.

PAX HD column formwork satisfies that brief. The unique feature of PAX HD is the patented folding mechanism that enables the formwork to be quickly opened, relocated and closed again.



Properties

Square and rectangular cross-sections from 20 x 20 cm to 60 x 60 cm or 50 x 50 cm to 120 x 120 cm can be set up in 5 cm increments. The maximum formwork height is virtually unlimited, and up to a lift of 4.80 m, there is no need to consider the rate of placing concrete.

Available in the following sizes

PAX HD column 320 x 60*
PAX HD column 270 x 60
PAX HD column 120 x 60
PAX HD extension panel 40 x 60
PAX HD column 320 x 120
PAX HD column 270 x 120
PAX HD column 120 x 120
PAX HD extension panel 40 x 120

*height x max. cross-section

Opening/closing procedure





Formwork setup time plotted against formwork area

  • Time-savings of up to 60%!
  • No assembly or disassembly
  • No loose parts and easy visual inspection of closing procedure
  • Infinite height adjustment
  • Easily relocated with just one crane lift
  • Wheels can be fitted for relocating without a crane
  • Columns in fair-face quality (edges, surfaces and joints)
  • Up to a lift of 4.80 m, no limit to the rate of placing concrete
